Black Copper Base PCB Board Production
|
Layer： |
1 Layer |
|
Material： |
Copper |
|
PCB Thickness： |
1.6mm |
|
Cu Thickness： |
2.0 OZ |
|
Min Line W/S： |
0.1/0.2mm |
|
Surface Finish： |
Immersion gold |
|
Certificate： |
UL/ISO/TS16949 |
|
Application： |
Power Electronics |
We will reply within 2 hours!
Product Parameters
Item | Specification |
Layers | 1~32 |
Board thickness | 0.1mm-7.0mm |
Material | FR-4，CEM-1/CEM-3，PI，High Tg，Rogers |
Max panel size | 32"×48"(800mm×1200mm) |
Min hole size | 0.075mm |
Min line width | 3mil(0.075mm) |
Surface finish | OSP，HASL，Imm Gold/Nickel/Ag， Electric gold |
Copper thickness | 0.5-7.0OZ |
Soldermask | Green/Yellow/Black/White/Red/Blue |
Silkscreen | Red/Yellow/Black/White |
Min PAD | 5mil(0.13mm) |
Inter package | Vacuum |
Outer package | Carton |
Outline tolerance | ±0.75mm |
Hole tolerance | PTH：±0.05 NPTH：±0.025 |
Certificate | UL，ISO 9001，ISO14001，IATF16949 |
Special request | Blind hole+Gold finger + BGA |
Material Suppilers | Shengyi, KB, Nanya, ITEQ,etc. |
General Introduction of Copper PCB
Copper core circuit boards are a type of metal core PCB. With their layered design using a copper base, these PCBs offer superior thermal conductivity. Base layer: The base layer is made of a copper substrate that offers high thermal conductivity and heat transfer.
(Printed Circuit Board Details Vedio )
PCB Manufacturing Services
As one of the leading Printed Circuit Board manufacturers based in China, Ucreate has been offering international companies of all sizes with high-quality PCB prototype to production services at a fair price for eight years. To make professional and advanced circuit boards, we're committed to adhering to the strictest standards during the PCB manufacturing process. We're fully compliant with the ISO 9001:2008 quality management system.
